QF-8112B EVA Mini Foaming Machine
1.Unique design in machine body structure, free from fracture and distortion.
2.The hydraulic pressure is controlled on a centralized basis. A filter is designed to extend the service life of the hydraulic parts.
3.The machine is designed with PF 125 prefill valve, which enables the machine to descend in a shortest time.
4.Semi-automatic and fully-automatic continuous operation are available to choose in the course of production. They are independent to adjust.
5.Hydraulic control system adopts imported famous brands. PC and PLC control systems are used.
2.The hydraulic pressure is controlled on a centralized basis. A filter is designed to extend the service life of the hydraulic parts.
3.The machine is designed with PF 125 prefill valve, which enables the machine to descend in a shortest time.
4.Semi-automatic and fully-automatic continuous operation are available to choose in the course of production. They are independent to adjust.
5.Hydraulic control system adopts imported famous brands. PC and PLC control systems are used.
| Model | Station Number | Heating Mode | Mole Closing Force | Horsepower | The Space For Mold(mm) | Layers | Machanical Dimensions(m) | Mould Opening Stroke（mm) |
| QF-8106B | 6 | 电、蒸汽、油 | 150 | 20 | 550x550 | 2 | 7.8x1.4x2.7 | 300 |
| QF-8110B | 10 | 电、蒸汽、油 | 150 | 20 | 550x550 | 2 | 12.03x1.4x2.7 | 300 |
| QF-8112B | 12 | 电、蒸汽、油 | 150 | 20 | 550x550 | 2 | 13.9x1.4x2.7 | 300 |
